Name: 24VDC Coil For Truck Solenoid Valve Repair Kit 4422002221 4423002221
Brand: Ningbo Brando Hardware Co., Ltd
SKU: BB11041041
Price: 49.10 USD
Availability: InStock

Ana sayfa Ürünler Solenoid Valf Bobini

24VDC Coil For Truck Solenoid Valve Repair Kit 4422002221 4423002221

Ürün ayrıntıları:

Menşe yeri:	NINGBO, ÇİN
Marka adı:	BRANDO
Sertifika:	None
Model numarası:	BB11041041

Ödeme & teslimat koşulları:

Min sipariş miktarı:	200
Fiyat:	Anlaşılabilir
Ambalaj bilgileri:	İç Kutu, Karton, Palet
Teslim süresi:	müzakere
Ödeme koşulları:	Banka havalesi, PayPal, Western Union
Yetenek temini:	Ayda 250000 parça

İletişim

Detaylı ürün tanımı

Ürün Adı:	Kamyon Solenoid Bobini	Gerilim:	24Vdc
Bağlayıcı:	4 pim	Nominal akım:	0.32A
OEM numarası:	4423002221, 4422002221, 4422012221, 4423012221, 4422022621, 1337734, 1337735, A0005433985, 42531617,
Vurgulamak:	Solenoid Valve for Scania WABCO 4423020021 , Wabco Valve Magnet 4423002221 , Truck Solenoid Valve Repair Kit

24VDC Coil For Truck Solenoid Valve Repair Kit 4422002221 4423002221

This is a 24VDC ECAS (Electronically Controlled Air Suspension) solenoid valve coil. It is designed as a replacement part for WABCO systems, with compatible OEM numbers including 4422002221 and 4423002221. The solenoid is intended for use in European commercial trucks, such as those from MAN, DAF, and Mercedes-Benz.

Dimension & Data of Truck Solenoid Valve Coil, Armature:

Truck ECAS Solenoid Valve Coil 24VDC for Wabco Type 4422002221 4423002221 0

BRANDO Model	BB11041041
Voltage	24VDC
Rated Current	0.32A
Other voltage and power can be customzied
Protection Class	IP 6K7, IP 6K9K
Electrical Connection	4 Pins

Truck ECAS Solenoid Valve Coil 24VDC for Wabco Type 4422002221 4423002221 1

BRANDO Model	BAPC311038505
Plunger Tube Material	Brass
Seal Material	NBR, FKM
Function	3 Way Normally Closed
Connection	Flange with O-ring Groove
