3/8'' Normally Open Brass Solenoid Valve PU225AN-03 220V 110V 24V

3/8'' Normally Open Brass Solenoid Valve PU225AN-03 220V 110V 24V

  • 3/8'' Normally Open Brass Solenoid Valve PU225AN-03 220V 110V 24V
3/8'' Normally Open Brass Solenoid Valve PU225AN-03 220V 110V 24V
Ürün ayrıntıları:
Menşe yeri: Çin
Marka adı: BRANDO
Sertifika: None
Model numarası: PU225A-03
Ödeme & teslimat koşulları:
Min sipariş miktarı: 1 adet
Fiyat: Anlaşılabilir
Ambalaj bilgileri: İç Kutu, Karton, Palet
Teslim süresi: Müzakere
Ödeme koşulları: Banka havalesi, Western Union, MoneyGram
Yetenek temini: Ayda 100000 adet
İletişim
Detaylı ürün tanımı
Bağlantı Noktası Boyutu: 3/8'' Delik boyutu: 13 mm
Çalışma Basıncı Aralığı: 0.05 ila 1 MPa İşlev: 2 Yollu Normalde Kapalı
Gövde Malzemesi: T/T,L/C Diyafram Malzemesi: NBR, FKM, EPDM
Gerilim: 12vdc, 24vdc, 24Vac, 110Vac, 220vac Operasyon: Diyafram Pilotlu
Vurgulamak:

Normally Open Brass Solenoid Valve 3/8''

,

Shako PU225AN-03

,

3/8 Inch Brass Solenoid Valve

3/8'' Normally Open Brass Solenoid Valve PU225AN-03 220V 110V 24V


The NOPU225 (or PU225AN) is a 2/2 way normally open valve will stay open until electrical power is applied, at which point the armature covers the pilot hole prevent media above the diaphragm venting downstream and the inlet pressure presses the diaphragm back into the closed position and the valve is fully closed.


Ordering Code of PU225A series Solenoid Valve:

3/8'' Normally Open Brass Solenoid Valve PU225AN-03 220V 110V 24V 0


Main Dimension of PU225A series Solenoid Valve:

3/8'' Normally Open Brass Solenoid Valve PU225AN-03 220V 110V 24V 1

PU225A Series
A
B
C
R
PU225A-03
66.5
106.5
48
3/8''
PU225A-04
66.5
106.5
48
1/2''
PU225A-06
96
126
70
3/4''
PU225A-08
96
126
70
1''
PU225A-12
131
145.5
96
1 1/4''
PU225A-14
131
145.5
96
1 1/2''
PU225A-20
160
160
112
2''


Technical Data of PU225A series Solenoid Valve:

Model
PU225A-03
PU225A-04
PU225A-06
PU225A-08
PU225A-12
PU225A-14
PU225A-20
PU225AN-03
PU225AN-04
PU225AN-06
PU225AN-08
PU225AN-12
PU225AN-14
PU225AN-20
Orifice Size
13mm
25mm
38mm
50mm
Port Size
3/8''
1/2''
3/4''
1'
1 1/4''
1 1/4''
2''
Medium
Water, Light Oil, Compressed Air
Action
Diaphragm Pilot Operated
NC/NO
2 Way, Normally Closed, Normally Open
Body Material
Brass
Seal Material
NBR (Standard); EPDM, FKM, Si (Optional)
Pressure
Range
0.05 to 1 MPa
Temperature Range
-5 to +80℃ (NBR), -5 to +150℃ (EPDM, FKM)
Voltages
24VDC, 110VAC, 220VAC, other voltage is optional



Brando Solenoid Valve Factory Production Video:



More Shako Type Solenoid Valves for you to choose:

3/8'' Normally Open Brass Solenoid Valve PU225AN-03 220V 110V 24V 2 3/8'' Normally Open Brass Solenoid Valve PU225AN-03 220V 110V 24V 3
PU220A Series PU225A Series
3/8'' Normally Open Brass Solenoid Valve PU225AN-03 220V 110V 24V 4 3/8'' Normally Open Brass Solenoid Valve PU225AN-03 220V 110V 24V 5
SPU225A Series PU225S Series
