Name: 1/8'' 1/4'' 2 Way Normally Open Stainless Steel Solenoid Valve 30bar
Brand: Ningbo Brando Hardware Co., Ltd
SKU: 19.13BAS
Price: 26.00 USD
Availability: InStock

Ana sayfa Ürünler Paslanmaz Çelik Solenoid Valf

1/8'' 1/4'' 2 Way Normally Open Stainless Steel Solenoid Valve 30bar

Ürün ayrıntıları:

Menşe yeri:	NINGBO, ÇİN
Marka adı:	BRANDO
Sertifika:	CE, ISO
Model numarası:	19.13BAS

Ödeme & teslimat koşulları:

Min sipariş miktarı:	50 adet
Fiyat:	Anlaşılabilir
Ambalaj bilgileri:	Kutu, karton, palet
Teslim süresi:	7 iş günü
Ödeme koşulları:	T/T, Paypal, Western Union
Yetenek temini:	Ayda 200000 adet

İletişim

Detaylı ürün tanımı

Ürün Adı:	Solenoid valfi	Bağlantı Noktası Boyutu:	1/8 '', 1/4 ''
Delik boyutu:	1,2 mm, 1,5 mm, 2 mm, 2,5 mm, 2,8 mm	Gövde Malzemesi:	Paslanmaz Çelik 304
Mühür Malzemesi:	NBR (Standard), EPDM, FKM (Önerilmez)	Çalışma Ortamı:	Hava, su, buhar, gaz, sıvı, hafif yağ vb.
Medya Sıcaklığı:	NBR (-10 ila +80°C), EPDM (-30 ila +120°C), FKM (-30 ila +150°C)	Çalışma basıncı:	0 ila 30 bar
Operasyon:	Piston Doğrudan Etkili	İşlev:	2 Yollu Normalde Açık
Gerilim:	12vdc, 24vdc, 24Vac, 110Vac, 220vac
Vurgulamak:	Normally Open Stainless Steel Solenoid Valve , 1/8'' Stainless Steel Solenoid Valve , 2 Way NO Solenoid Valve

1/8'' 1/4'' 2 Way Normally Open Stainless Steel Solenoid Valve 30bar

This is a small and compact solenoid valve, 1/8'' or 1/4'' port, 1.2 to 2.8mm orifice, 0 to 30 bar, plunger direct acting, 2 way normally open, stainless steel 304 body, NBR standard seal, can be customized as EPDM or FKM seal to suit different working mediums, various voltages for your choice, such as 12VDC, 24VDC, 24VAC, 110VAC and 220VAC, etc. It is used for a wide arrange of industrial applications to control fluids.

Technical Data:

Model No	Port Size (inch)	Orifice Size (mm)	Cv	Working Pressure (bar)		Body	Seal	Voltage
Model No	Port Size (inch)	Orifice Size (mm)	Cv	DC	AC	Body	Seal	Voltage
2 Way Normally Closed, Direct Acting
19.13BAX012BXX	1/8'' 1/4''	1.2	0.09	0 to 30	0 to 30	Brass SS304	NBR EPDM FKM	12VDC 24VDC 24VAC 110VAC 220VAC
19.13BAX015BXX		1.5	0.11	0 to 30	0 to 30
19.13BAX020BXX		2.0	0.15	0 to 20	0 to 15
19.13BAX025BXX		2.5	0.18	0 to 14	0 to 10
19.13BAX028BXX		2.8	0.25	0 to 10	0 to 8
2 Way Normally Open, Direct Acting
19.13BBX012KXX	1/8'' 1/4''	1.2	0.09	0 to 10	0 to 10	Brass SS304	NBR EPDM FKM	12VDC 24VDC 24VAC 110VAC 220VAC
19.13BBX015KXX		1.5	0.11	0 to 9	0 to 9
19.13BBX020KXX		2.0	0.15	0 to 6	0 to 6
19.13BBX025KXX		2.5	0.18	0 to 4	0 to 4
19.13BBX028KXX		2.8	0.25	0 to 3	0 to 3
