Name: ASCO Type 322108 HYT Diaphragm For 8353J039 Pulse Jet Valve Replacement Kit
Brand: Ningbo Brando Hardware Co., Ltd
SKU: 322108
Price: 49.10 USD
Availability: InStock

Ana sayfa Ürünler Diyafram Tamir Takımı

ASCO Type 322108 HYT Diaphragm For 8353J039 Pulse Jet Valve Replacement Kit

Ürün ayrıntıları:

Menşe yeri:	Çin
Marka adı:	BRANDO
Sertifika:	CE, ISO
Model numarası:	322108

Ödeme & teslimat koşulları:

Min sipariş miktarı:	5 Set
Fiyat:	Anlaşılabilir
Ambalaj bilgileri:	Poşet, Kutu, Karton, Palet
Teslim süresi:	3 ila 5 iş günü
Ödeme koşulları:	Banka havalesi, Paypal, Western Union
Yetenek temini:	Ayda 100000 set

İletişim

Detaylı ürün tanımı

Ürün Adı:	Darbe valfi diyaframı	Takılı Nabız Valfi Bağlantı Noktası Boyutu:	1 1/2 ''
Takılı darbe valf modeli:	8353J039	Diyafram malzemesi:	HYT (HİTREL)
Renk:	Beyaz, Siyah	1 takım:	1x Büyük Diyafram, 1x Küçük Diyafram, 1x Yay
Vurgulamak:	ASCO Diaphragm 322108 , ASCO HYT Diaphragm , Pulse Valve Diaphragm Repair Kit

ASCO Type 322108 HYT Diaphragm For 8353J039 Pulse Jet Valve Replacement Kit

The diaphragm is the most important part of the pulse valve. When the pulse valve is energised, the trapped air above pulse valve diaphgram is quickly exhausted causing fast opening of main diaphragm valve. When the pulse valve is de-energised , air escapes through bleed hole of main pulse valve to balance the diaphragm pressure and instantly closes the pulse valve.

Overall Dimension of 322108 Diaphragm:


Main Diaphragm	Secondary Diaphragm

Model No of Pulse Valve Diaphragm:

Integral Pilot Pulse Valve Model No	Remote Pilot Pulse Valve Model No	Pulse Valve Port Size	Diaphragm Model	Diaphragm Model (10 pack)	Diaphragm Material
-	8353C033	3/4''	96875	238864	NBR diaphragm
-	8353C030	3/4''	96875	238864	NBR diaphragm
-	8353C004	3/4''	96875	238864	NBR diaphragm
-	8353C035	1''	200262	238866	HYTREL diaphragm
8353G041	-	1''	316563	238866	HYTREL diaphragm
8353G006	-	1''	300144	-	CR diaphragm, PA disc
8353G005	-	1 1/4''	300144	-	CR diaphragm, PA disc
8353G001	-	1 1/2''	300144	-	CR diaphragm, PA disc
-	8353H038	1 1/2''	276886	238870	HYTREL diaphragm
8353J039	-	1 1/2''	322108	238870	HYTREL diaphragm
8353G061	-	1 1/2''	316297	-	NBR diaphragm, PA disc
-	8353A062	1 1/2''	276884	-	NBR diaphragm, PA disc
8353G002	-	2''	300145	-	CR diaphragm, PA disc
-	8353 048	2''	256802	256797	CR diaphragm
8353G050	-	2''	316029	256797	CR diaphragm
8353G007	-	2 1/2''	176878	-	CR diaphragm, PA disc
8353G008	-	3''	176878	-	CR diaphragm, PA disc

Our Production of Pulse Valve Diaphragm:

ASCO Type 322108 HYT Diaphragm For 8353J039 Pulse Jet Valve Replacement Kit 2
